Gate valves: versatile solutions for every application
Gate valves are designed for isolation in pipe networks, ideal for fully open or fully closed situations. Their design minimizes pressure loss and guarantees a full bore, making them perfect for applications requiring laminar flow. Gate valves are used in hydrocarbons, general process environments, and water and utility services, with applications suitable for all temperature conditions. They offer low pressure drop, can be used in all directions, and, thanks to their smooth movement, pose no risk of water hammer.
With versions tested according to DIN EN 12266 and inspections according to API 598 and ASME B16.34, these valves offer reliability and quality for any industrial application. Contact us for the right solution for your project.
Rising handwheel
Largely available from stock
Delivery sometimes within 24 hours
Oil & gas
Chemicals
Durable
Pharmacy
Non-rising handwheel
Usually available from stock
Delivery sometimes within just 24 hours
Oil & gas
Chemicals
Durable
Pharmacy
Internal spindle
Often available from stock
Delivery within 24 hours in some cases
Oil & gas
Chemicals
Durable
Pharmacy
External spinner
Available from stock in most cases.
Delivery sometimes within just 24 hours
Oil & gas
Chemicals
Durable
Pharmacy
Conical slide valve
Regularly available from stock
Delivery sometimes within just 24 hours
Oil & gas
Chemicals
Durable
Pharmacy
Parallel slide
Almost always available from stock
Delivery sometimes within just 24 hours
Oil & gas
Chemicals
Durable
Pharmacy
Gate valves are used both above ground and underground for a wide variety of applications. They are used as isolation valves in a pipeline network. Gate valves are designed for a fully open or fully closed situation. Gate valves are also perfect in arrangements where a minimum pressure loss is allowed and full bore must be guaranteed.
BÈTA industrie supplies a complete range of high quality cast gate valves in DIN and ANSI versions. The uniqueness of this program is that we are able to deliver largely from stock, even the larger versions (up to 24”). Gate valves are used for on/off operation in hydrocarbons, general process applications, water and utility service in all possible temperature ranges. Gate valves create a laminar flow and have a low pressure drop through the entire opening. They can be used in all directions, close well and have no risk of water hammer due to the gradual opening and closing. BÈTA industrie supplies all possible types;
Sealing material depending on the application, this can optionally be metallic sealing. The sealing material is available in DIN and ANSI, pressure classes from full vacuum to PN 100 (and ANSI 600#) and temperature range from cryogenic to 425oC. It is also available in stainless steel, carbon steel, nodular cast iron, cast iron and bronze. All our gate valves are tested in accordance with DIN EN 12266. Dimensions from ½” to 24” are usually available from stock.
BÈTA industrie supplies custom gate valves for special applications in the oil and gas industry, for example slab gate valves in ANSI 900#, ANSI 1500# and ANSI 2500#. Trim materials F6, F304, stellite, monel, F316 and Alloy20 and other exotic materials. Special versions in wrought iron. Provided with all necessary certificates. Wall thickness according to API 600. Testing and inspection according to API 598 and ASME B16.34.
Our gate valves are largely available from stock, so we can sometimes guarantee delivery within 24 hours. Are you curious about which type of valve fits best in your installation? Then let one of our specialists inform you. This can be done by telephone on: +31 79 341 55 18 or simply via the button below.
