Complete program of pleated filter cartridges

At BÈTA industrie we supply a complete program of pleated filter cartridges. Our standard is (Beta 5000 99.98% absolute) batch filtration. For batches that need to be filtered very accurately, pleated filter cartridges are often used. Below are the advantages of pleated cartridge filters:

  • Absolute filter quality (BETA 5000, 99.98% absolute)
  • 30% to 70% smaller filter housings required (lower investment costs)
  • Large filter surface (low pressure drop, large dirt trapping capacity, long service life), up to 4 m2 per filter cartridge
  • Optimal sealing due to the O-ring construction
  • Easy filter changes
  • Horizontal installation is possible
  • Lower waste costs (how much captured dirt per kg of filter material)

Pleated filter cartridges in different types

The BÈTA Pleated filter cartridges are available in different lengths; 10”, 20”, 30”, 40” and 60”. Our Pleated cartridge filters are also available in different types of material: Polypropylene, Polyester, Fiberglass, Nylon, PTFE and PVDF. Various support materials; Polypropylene, Polyester, PTFE, PVDF and Glass fiber reinforced. Filter Finenesses: 0.2 to 100 microns Beta 5000 (99.98% absolute filtration). O-ring: EPDM, viton, silicone, NBR, FEP. Outer diameter 6”. Single open end, flow outside to in. The flow per pleated cartridge filter is a maximum of 4 m3/h, filter housings are available with 1, 3, 4, 5, 7 to 100 filter cartridges per filter housing.

Pleated cartridge filter production

Production of our pleated cartridge filters takes place in a strictly controlled and conditioned production facility within Europe. This allows us to guarantee the highest quality filter cartridges and therefore to deliver them quickly. The filter cartridges also have various certificates such as: FDA, CFR 21, PDA, Cleanroom, etc.

Pleated filter cartridges for your application

The pleated filter cartridges are used for various applications. BÈTA industrie also supplies a complete program of filter housings that are suitable for pleated filter cartridges. Our specialists are happy to advise you on all options. You can easily contact one of our specialists, this can be done by telephone on +31 79 341 55 18 or simply via the button below!
